Skyline R33 GTR/R34 GTT - Xtreme Performance Pull Type Heavy Duty Organic 610Nm 1170kg (40% inc.) KNI25003-1B
Xtreme Performance - sprung ceramic kit /-1B
Recommended for: Motorsport/Road Applications
These kits are available with sprung ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.
Torque capacity 920Nm
Clamp load 1170kg 40% Increased over standard
Sprung Ceramic Friction Disc
Heavy Duty Pressure Plate
Kit contains everything you need for a successful installation + accessories
The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.
At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.
What's in the Box?
Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.
Clamp Load1170Kg (40% inc.)
Clutch Disc Diameter (mm)250
Clutch Disc Spline Count24
Clutch Disc Spline Diameter (mm)25,5
Recommended forTrack - Stage 2
|Make||Model||Engine / Year||Notes|
|NISSAN||SKYLINE||2.5 147KW (1998-2000)||Pull Type|
|NISSAN||SKYLINE||2.5 206KW (1998-2002)||Pull Type|
|NISSAN||SKYLINE||2.5 4x4 147KW (1998-2000)||Pull Type|
|NISSAN||SKYLINE||2.5 Turbo 206KW (1998-2006)||Pull Type|
|NISSAN||SKYLINE||2.6 Twin Turbo 4x4 206KW (1989-1995)||Pull Type|
|NISSAN||SKYLINE||2.6 Twin Turbo 4x4 206KW (1994-1999)||Pull Type|
|NISSAN||STAGEA||2.5 Turbo AWD 173KW (1996-2001)||Pull Type|
|NISSAN||STAGEA||2.6 Twin Turbo 206KW (1996-2001)||Pull Type|
